SANWA SUPPLY
DisplayPort Fiber Optic Cable 30m KC-DPFB300
DisplayPort Fiber Optic Cable 30m KC-DPFB300
GTIN（JAN）：4969887762660
SKU：KC-DPFB300
Regular price
¥100,188 JPY
Regular price
Sale price
¥100,188 JPY
Quantity
Couldn't load pickup availability
Important: Return Policy
Please review your order carefully before completing the purchase. We do not accept returns or exchanges for customer errors (e.g., wrong size, color, or accidental purchase)
[4K/60Hz Compatible DisplayPort Fiber Optic Cable 30m]
●This is a fiber optic cable that connects a computer equipped with DisplayPort to a display.
●Uses 850nm optical fiber that can transmit stable signals even over long distances.
●This cable is compatible with the DisplayPort standard Ver.1.2.It supports a maximum transmission speed of 21.6Gbps (5.4Gbps x 4 lanes) and can display high resolutions up to 4K2K/60Hz.
●It can transmit both image and sound with a single cable.
(Audio signal input and output are optional functions of the equipment, so compatible equipment is required.)
●Multiple displays can be daisy-chained or connected via a hub, making it easy to build a multi-display environment.
●Supports DPCP (DisplayPort Content Protection) and HDCP (High-bandwidth Digital Content Protection), copyright protection technologies that prevent unauthorized copying of content.
●Uses gold-plated pins to reduce contact resistance and suppress deterioration over time due to rust, etc., preventing degradation of image and sound quality.
＜Precautions when connecting the cable to a device＞
When inserting the DisplayPort connector, make sure the logo on the connector cover is facing upwards, and insert it straight, slowly, and securely.When removing the connector, hold the connector while pressing the button on the upper surface (resin part) of the connector cover, and pull it out slowly and straight.
*When connecting this product to each device, please read the device's instruction manual carefully before proceeding.
*When inserting or removing this product, always hold the connector part and do not apply excessive force. Pulling the cable or applying excessive force may cause damage or malfunction.
*This product has a signal direction. It cannot be used if connected in the wrong direction (to the wrong device).
■Color: Black
■Cable length: Approximately 30m (between SRs)
*SR refers to the part that protects the connection between the rear end of the connector and the cable.
■Maximum Resolution: 4K/60Hz
■Connector Shape: DisplayPort Male - DisplayPort Male
■Sheath Material: PU
■Cable Diameter: Approx. 4.8mm
■Compliant Standards: Displayport Ver.1.2 Compatible (Not Certified)
≪Custom Orders Not Accepted≫
We cannot accept custom orders for small quantities. Depending on the quantity, it may be possible, so please contact Sanwa Supply Sales for details.
●This is a fiber optic cable that connects a computer equipped with DisplayPort to a display.
●Uses 850nm optical fiber that can transmit stable signals even over long distances.
●This cable is compatible with the DisplayPort standard Ver.1.2.It supports a maximum transmission speed of 21.6Gbps (5.4Gbps x 4 lanes) and can display high resolutions up to 4K2K/60Hz.
●It can transmit both image and sound with a single cable.
(Audio signal input and output are optional functions of the equipment, so compatible equipment is required.)
●Multiple displays can be daisy-chained or connected via a hub, making it easy to build a multi-display environment.
●Supports DPCP (DisplayPort Content Protection) and HDCP (High-bandwidth Digital Content Protection), copyright protection technologies that prevent unauthorized copying of content.
●Uses gold-plated pins to reduce contact resistance and suppress deterioration over time due to rust, etc., preventing degradation of image and sound quality.
＜Precautions when connecting the cable to a device＞
When inserting the DisplayPort connector, make sure the logo on the connector cover is facing upwards, and insert it straight, slowly, and securely.When removing the connector, hold the connector while pressing the button on the upper surface (resin part) of the connector cover, and pull it out slowly and straight.
*When connecting this product to each device, please read the device's instruction manual carefully before proceeding.
*When inserting or removing this product, always hold the connector part and do not apply excessive force. Pulling the cable or applying excessive force may cause damage or malfunction.
*This product has a signal direction. It cannot be used if connected in the wrong direction (to the wrong device).
■Color: Black
■Cable length: Approximately 30m (between SRs)
*SR refers to the part that protects the connection between the rear end of the connector and the cable.
■Maximum Resolution: 4K/60Hz
■Connector Shape: DisplayPort Male - DisplayPort Male
■Sheath Material: PU
■Cable Diameter: Approx. 4.8mm
■Compliant Standards: Displayport Ver.1.2 Compatible (Not Certified)
≪Custom Orders Not Accepted≫
We cannot accept custom orders for small quantities. Depending on the quantity, it may be possible, so please contact Sanwa Supply Sales for details.
