SANWA SUPPLY
CRT composite coaxial cable KB-CHD1520K2
CRT composite coaxial cable KB-CHD1520K2
GTIN（JAN）：4969887846834
SKU：KB-CHD1520K2
Regular price
¥17,787 JPY
Regular price
Sale price
¥17,787 JPY
Quantity
Couldn't load pickup availability
Important: Return Policy
Please review your order carefully before completing the purchase. We do not accept returns or exchanges for customer errors (e.g., wrong size, color, or accidental purchase)
[Display Cable 20m VGA Composite Coaxial Type]
●This cable connects a computer with a mini D-sub 15-pin display terminal to a display, projector, etc., and also to a switch or splitter.
●This is a composite coaxial cable that uses 75-ohm coaxial cable for the R, G, and B video signals.It is highly resistant to noise and has extremely low signal loss, making it a high-quality cable with very little image degradation even in high-resolution modes.
●It is a double-shielded cable with a sealed aluminum shield inside a high-density braided copper shield, protecting important data from most noise from low to high frequencies.
●It uses noise-resistant twisted pair wires with two core wires twisted together.
●The molded connector has the inside solidified with resin molding and further shielded on all sides, preventing external interference and providing complete noise protection. It also has excellent vibration and shock resistance.
●It uses gold-plated pins (contacts) that are highly resistant to rust and have little concern about signal degradation due to aging.
●Equipped with a ferrite core that functions as a noise filter to effectively absorb noise transmitted from the cable.
●Lead-free solder, which contains almost no lead, is used to fix the cable's core wires to the pins inside the connector.
●Complies with the VESA DDCI standard and is compatible with Windows 95 Plug & Play.
■Color: Light Gray
■Cable Length: 20m
■Connector Shape:
Mini D-sub (HD) 15-pin male inch screw (4-40) -
Mini D-sub (HD) 15-pin male inch screw (4-40)
■Cable Diameter: 9mm
■Cable Standard: UL2919
■Wiring: Straight through wiring
≪Custom Orders Available≫
Custom production such as changing the length is possible from just one unit.
*For custom orders of one unit or more, the connector material will be the one specified by Sanwa Supply. We cannot accept custom orders for small quantities of molded or PC98-colored connector cables. Thank you for your understanding.
●This cable connects a computer with a mini D-sub 15-pin display terminal to a display, projector, etc., and also to a switch or splitter.
●This is a composite coaxial cable that uses 75-ohm coaxial cable for the R, G, and B video signals.It is highly resistant to noise and has extremely low signal loss, making it a high-quality cable with very little image degradation even in high-resolution modes.
●It is a double-shielded cable with a sealed aluminum shield inside a high-density braided copper shield, protecting important data from most noise from low to high frequencies.
●It uses noise-resistant twisted pair wires with two core wires twisted together.
●The molded connector has the inside solidified with resin molding and further shielded on all sides, preventing external interference and providing complete noise protection. It also has excellent vibration and shock resistance.
●It uses gold-plated pins (contacts) that are highly resistant to rust and have little concern about signal degradation due to aging.
●Equipped with a ferrite core that functions as a noise filter to effectively absorb noise transmitted from the cable.
●Lead-free solder, which contains almost no lead, is used to fix the cable's core wires to the pins inside the connector.
●Complies with the VESA DDCI standard and is compatible with Windows 95 Plug & Play.
■Color: Light Gray
■Cable Length: 20m
■Connector Shape:
Mini D-sub (HD) 15-pin male inch screw (4-40) -
Mini D-sub (HD) 15-pin male inch screw (4-40)
■Cable Diameter: 9mm
■Cable Standard: UL2919
■Wiring: Straight through wiring
≪Custom Orders Available≫
Custom production such as changing the length is possible from just one unit.
*For custom orders of one unit or more, the connector material will be the one specified by Sanwa Supply. We cannot accept custom orders for small quantities of molded or PC98-colored connector cables. Thank you for your understanding.
