Digital Cable Measurer DMJ-1000RA

[Product Features]
Quickly measure the length of single cables (IV, CV)!
●Easy operation! Simply connect it to both ends of the wire and press the button.
● Quickly measure the length of 600V vinyl insulated wire (IV), etc.
● Measures up to 1000m *1
● 10 user modes
Allows measurement of wires of unknown size *2
*1 1.25mm stranded wire up to 600m
*2 Requires a "reference wire" of the same specifications and known length
● Compatible cables
・600V vinyl insulated wire (IV wire), power cable (600V CV)
● Compatible sizes
・Solid wire
1.6, 2.0, 2.6mm
・Stranded wire
1.25, 2, 3.5, 5.5, 8, 14, 22, 38, 60, 100, 150, 200, 250, 325mm_
■ Specifications
・Body size and weight (body only, including batteries): 80mm x 29mm x 150mm / 200g
・Measurement method: Resistance measurement method
・Measurement range: 1 to 1000m (varies depending on the cable)
・Measurement accuracy: ±5%
・Measurable cable: Electrical soft copper wire JIS C3102
・Resolution: Less than 100m: 0.1m / 100m or more: 1m
・Display: LCD
・Operating temperature range: 0°C to 40°C (80%RH or less)
・Auto power off function: Automatically turns off after approximately 3 minutes of inactivity
・Battery replacement notification function: POWER LED flashes
・Battery used: 2 x AA alkaline batteries (batteries not included)
・Continuous use time: Approximately 10 hours (alkaline batteries)
・Material
ABS
・Packaging specifications
Individual packaging: Plastic case and cardboard backing (sleeve)
Individual package size and weight: W210 x D50 x H200mm, 560g
・1 package
・Country of origin: Japan
【Precautions】
※Warning: Not for use on live wires
※Cables that branch in the middle or cables connected with crimp terminals, sleeves, etc. cannot be measured.
※Cables that are more than 2m apart at both ends cannot be measured due to the length limitations of the included cable.
